Annilte SBR rubber EP 100/150/200/300 flat conveyor belt black Cold resistant /acid and alkali resistant rubber conveyor belt

Product Classification
According to whether there is edge rubber: Molded edge belt and Cut edge belt.

According to the fabric type:
Polyester (EP) canvas conveyor belt (polyester belt, EP belt);
Nylon (NN) canvas conveyor belt (nylon belt, NN belt);
Cotton(CC) canvas conveyor belt(cotton belt, CC belt).

Product Use
It is widely used in coal, mining, port, metallurgy, electric power, chemical industry, casting, building materials, cement and other industries and places that need high-speed and fast transportation of materials, and it is used to transport non-corrosive block, granular, powder materials, bulk materials or finished articles.

Product Detail

Product Tags

Product Structure
The general purpose fabric conveyor belt is made of multi-ply rubberized nylon (NN) canvas, polyester (EP) canvas or cotton(CC) canvas as the skeleton material, covered with coating rubber with different properties, and manufactured through calendering, molding, vulcanization and other processes.

The Conveyor Shop supply a large range of Conveyor Belts. We take pride in the quality and high standards of the Conveyor Belts we supply.

The Conveyor Shop also has many tools on site to repair and join your Conveyors, which you can purchase.

The most celebrated belting today is the EP range this is a fabric ply. The range works well from 2 - 5 plys.

We supply all different designs and sizes

EP polyester conveyor belt refers to the conveyor belt made of EP polyester canvas as the skeleton. The structure is multi-layer or a layer of EP polyester canvas. The core rubber and rubber coating are integrated into one through the vulcanization process. In the case of ultra-wide or large bearing capacity and high speed, one or two layers of steel mesh anti-tear layer can be added to increase the transverse tensile strength of the conveyor belt, and the longitudinal tear of the conveyor belt can be effectively avoided.

EP canvas is divided into the following types

EP100 EP125 / EP150 / ER200 / EP250 / EP300 / EP350 / EP400 #, each type of value represent a single canvas tensile strength, such as 100 n/mm, 125 n/mm, 150 n/mm, 200 n/mm."

"Polyester conveyor belt is one of the conveyor belts needed in industrial production. Also known as EP conveyor belt. In many ways, it is wear-resistant, can also be called wear-resistant conveyor belt, and a lot of it is used for conveying cement and other products, so it is also called cement conveyor belt. Mainly suitable for medium and long distance, high cutting, high speed conveying materials.

Polyester conveyor belt structure

Polyester conveyor belt is also known as strong conveyor belt. Including nylon conveyor belt (nylon canvas core conveyor belt), polyester conveyor belt (polyester canvas core conveyor belt), nylon polyester interleaved core conveyor belt, suitable for mid-span conveying line, conveying powder, granular and block non-corrosive materials. Such as coal, sand, stone, etc.

Polyester conveyor belt product features

1. Good elasticity and impact resistance polyester canvas has unique elasticity and can absorb impact well.

2 The elongation under dead load is very small. The dead load elongation of small elongation polyester canvas conveyor belt is better than that of nylon conveyor belt and other fabric core conveyor belt. In the process of use can shorten the discharge stroke, save equipment cost, suitable for long distance material conveying.

3 Good water resistance. When used in humid environment, the adhesive temperature of adhesive tape is not reduced, which prolongs the service life of adhesive tape.

4Good heat and corrosion resistance.

5 Belt body thin, light weight. As the strength of polyester canvas is about 2.5 to 9 times that of cotton sail, the layer thickness can be reduced compared with cotton canvas conveyor belt, so the belt body is thin, light weight, and good grooving. It can not only improve the transmission performance, but also reduce the transmission power, and relatively reduce the pulley diameter, to achieve the purpose of saving.



rubber conveyor belt test1 rubber conveyor belt test2

Scope of Application

1 Conveyor belt is mainly used in the manufacture of kraft paper and corrugated conveyor belt of kraft paper.

2 Skirt side polyester conveyor belt is mainly used in the paper industry and to replace the dry parts of paper machine blankets and canvas. Widely used in coal mine, food, medicine and other industries of equipment conveyor belt.

3. High-temperature resistant polyester conveyor belt is mainly suitable for high pressure filter press, horizontal belt washing machine, slurry separator, mesh belt shearer, mechanical conveyor belt, sludge dewatering equipment and so on in the coal preparation industry.

detail

Cover Rubber grade 8MPA, 10MPA, 12MPA, 15MPA DIN-X, Y, W
18MPA, 20MPA, 24MPA, 26MPA RMA-1, RMA-2
N17, M24
Belt width (mm) 500, 600.650, 700, 800, 1000, 1200 18", 20", 24", 30", 36", 40", 42"
140, 015, 001, 800, 200, 000, 000, 000 48", 60", 72", 78", 86", 94"
Tensile strength EP315/3, EP400/3, EP500/3, EP600/3 330PIW, 440PIW
EP400/4, EP500/4, EP600/4
EP500/5, EP1000/5, EP1250/5
EP600/6, EP1200/6
Top+Bottom thickness 3+1.5, 4+2, 4+1.5, 4+3, 5+1.5 3/16"+1/16", 1/4"+1/16"
Belt thickness 3mm, 4mm, 5mm, 6mm, 7mm, 8mm, 9mm, 10mm, 12mm, 15mm, 20mm, 25mm
Belt length 10m, 20m, 50m, 100m, 200m, 250m, 300m, 500m
Belt edge type moulded(sealed) edge or cut edge

Details pictures

detail
detail
detail
detail
