Large Inclination Edge Rubber conveyor belt
Environmentally friendly large inclination angle baffle conveyor belt is to set covering belt on the structure of ordinary baffle conveyor belt, so as to achieve the effect of airtight conveying. It avoids dust flying and leakage, and reduces the pollution to the environment.
2、Parameters of conveyor belt
| Height of retaining edge (mm) | 60 | 80 | 120 | 160 | 200 | 240 | 300 | 400 |
| Flange quality (kg/m) | 1.1 | 1.3 | 2.9 | 4.6 | 5.0 | 7.0 | 12 | 15 |
| Height of baffle (mm) | 40 | 75 | 110 | 140 | 180 | 220 | 280 | 360 |
| Bulkhead quality (kg/m) | 1.2 | 1.4 | 3.5 | 3.5 | 5.4 | 7.5 | 12 | 15 |
| Baseband width (mm) | 500 ~2000 | |||||||
3、Use
It is suitable for conveying materials under the condition of high inclination angle of 0°~90°.
Characteristics
1．When conveying materials, the inclination angle can be up to 90°.
2. Large conveying capacity, materials will not be scattered.
3. It is easy to transition from horizontal to inclined and from inclined to horizontal angle and change the conveying.
4. The conveyor is compact and covers a small area.
| Relationship between inclinationangle and conveying capacity of curb conveyor belt | 60 | 80 | 100 | 135 | 150 | 200 | |
| 45 | 330 250 200 160 |
73 | 137 | 191 | 126 233 266 299 |
230 305 338 |
383 |
| 50 | 330 250 200 160 |
60 | 90113 | 109 131 164 |
146 194 232 272 |
198 264 304 344 |
328408 |
| 55 | 330 250 200 125 |
68 | 77128 | 93 111 183 |
124 124 198 |
169 225 269 |
279 366 413 |
| 60 | 330 250 200 125 |
59 | 66110 | 95159 | 142170 | 145 193 232 |
239 319 374 |
| 65 | 330 250 200 125 |
51 | 5785 | 83138 | 123147 | 125 167 201 |
207 277 332 |
| 70 | 330 250 200 120 |
44 | 5083 | 72120 | 107 128 214 |
109 149 175 |
181 241 289 |
| 75 | 330 250 200 125 |
38 | 4372 | 63105 | 93 112 186 |
95 127 152 |
157 210 212 |
5、波形挡边组合数SIDEWALL AND CLEAT
| 基带宽 B(mm) |
挡边高 H(mm) |
横隔板高 H1(mm) |
波底宽 Bf(mm) |
有效宽度 Br(mm) |
空边宽 R(mm) |
| 300 | 40 | 35 | 25 | 180 | 35 |
| 60 | 55 | 50 | 120 | 40 | |
| 80 | 75 | ||||
| 400 | 60 | 55 | 50 | 180 | 60 |
| 80 | 75 | ||||
| 100 | 90 | ||||
| 500 | 80 | 75 | 50 | 250 | 75 |
| 100 | 90 | ||||
| 120 | 110 | ||||
| 650 | 100 | 90 | 50 | 350 | 100 |
| 120 | 110 | ||||
| 160 | 140 | 75 | 300 | ||
| 800 | 120 | 110 | 50 | 460 | 120 |
| 160 | 140 | 75 | 410 | ||
| 200 | 180 | ||||
| 1000 | 160 | 140 | 75 | 550 | 150 |
| 200 | 180 | ||||
| 240 | 220 | ||||
| 1200 | 160 | 140 | 75 | 690 | 180 |
| 200 | 180 | ||||
| 240 | 220 | ||||
| 300 | 260 | 105 | 630 | ||
| 1400 | 200 | 180 | 75 | 830 | 210 |
| 240 | 220 | ||||
| 300 | 260 | 105 | 770 | ||
| 400 | 360 | ||||
| 1600 | 200 | 180 | 75 | 970 | 240 |
| 240 | 220 | ||||
| 300 | 260 | 105 | 910 | ||
| 400 | 360 | ||||
| 1800 | 240 | 220 | 75 | 1110 | 270 |
| 300 | 260 | 105 | 1050 | ||
| 400 | 360 | ||||
| 500 | 460 | 125 | 1010
|
