Polyester Mesh Conveyor Belt have the characteristics of tear-resistance, shrink-resistance and abrasion resistance etc.
Polyester Monofilament process conveyor belting is available in a wide variety of yarn thicknesses and apertures. Polyester mesh belting is characterised by high reliability, easy handling, thermal and chemical resistance coupled with dimensional stability.
Polyester Mesh Conveyor Belt Techinical Data
The jointing mechanism of the belts is given special attention and can be manufactured in a number of ways ranging from metallic clipper types to integrated spirals. The edges too are given extra attention and can be reinforced with special materials that make them resistant to fraying and abrasion by impregnation, encapsulation or RF welding.
| Polyester Mesh Conveyor Belt | |||||||
| Weaving Type | Model | Thread Diameter | Density(No.s/cm) | Srength (N/cm) | Air Permeability (m³/m²h) | ||
| (mm) | |||||||
| Warp | Weft | Warp | Weft | ||||
| 2-shed plain weaving fabric | AN_PO01 | 0.75 | 0.8 | 4.7-5 | 4.8-5 | 940 | >20000 |
| AN_PO02 | 1 | 1 | 4.7-5.2 | 4.3-5 | 1600 | >15000 | |
| AN_PO03 | 0.7 | 0.7 | 8 | 7 | >=1600 | 11000 | |
| AN_PO04 | 0.7 | 1 | 6.6-7 | 4.3-4.6 | 1100 | >15000 | |
| AN_PO05 | 0.55 | 0.55 | 7.5-8 | 8.5-9 | 850 | 850-6500 | |
| AN_PO06 | 0.45 | 0.45 | 10 | 8.6 | 1600 | 16000 | |
| AN_PO07 | 0.5 | 0.5 | 8.5-9 | 10-10.5 | 750 | >10000 | |
| AN_PO08 | 0.5 | 0.5 | 13.5 | 8.5 | 1800 | 6500 | |
| 3-shed plain weaving fabric | AN_PO09 | 0.5 | 0.6 | 10 | 9 | 1600 | 14000 |
| AN_PO10 | 0.9 | 0.9 | 7.8-8 | 5-5.5 | 2100 | 7500-8500 | |
| AN_PO11 | 0.7 | 0.8 | 8 | 8 | 1600 | 10000 | |
| AN_PO12 | 0.3 | 0.35 | 22 | 14.5 | 1200 | 13000 | |
| AN_PO13 | 0.3 | 0.4 | 22 | 14.5 | 1200 | 13500 | |
R&D Team
Annilte has a research and development team consisting of 35 technicians. With strong technical research and development capabilities, we have provided conveyor belt customization services for 1780 industry segments, and gained recognition and affirmation from 20,000+ customers. With mature R&D and customization experience, we can meet the customization needs of different scenarios in various industries.
Production Strength
Annilte has 16 fully automated production lines imported from Germany in its integrated workshop, and 2 additional emergency backup production lines. The company ensures that the safety stock of all kinds of raw materials is not less than 400,000 square meters, and once the customer submits an emergency order, we will ship the product within 24 hours to respond to the customer's needs efficiently.
Annilte is a conveyor belt manufacturer with 15 years of experience in China and an enterprise ISO quality certification. We are also an international SGS-certified gold product manufacturer.
We offer a wide range of customizable belt solutions under our own brand, "ANNILTE."
Should you require further information regarding our conveyor belts, please do not hesitate to contact us.
